transformer winding machine



Our RX series coil winding machine has passed ISO9001-2008, CE, patent certificate, and exporting assurance quality certificate by Chinese CIQ. Our machine has been sold at home and abroad widely, and get high praise from client. 10 years gold supplier in alibaba website.



Instruction

Based on client requirement and advantage of coil winding machine both home and abroad, we designed and manufactured this horizontal coil winding machine. This kind machine is unique, professional, esay operating, digital showing and get high praise from user. This machine is widely used in electric transformer, electic motor coil industry, etc. many famous companies have use our machine like Toshiba of Japan, Luneng electrics, etc. big electric industries.



1, Performance and working environment

1-1 performance:

1) reliable working, convenient operation; starting and braking smoothly.

2) positive and reversal winding can be achieved by foot switch and control box. Screen can display the winding number of positive and reversal, and remember the data when the electric stops.

3) parts of machine are standard and bought from formal manufacture. Transducer, PLC and screen are all imported from famous and high quality foreign companies.

4) safe and reliable working; flexible operating, no blocking.

5) outline is tidy and prety.

1-2, working environment

Normal working environment

1) right installation on steady foundation

2) clean environment without vibration, corrosion and strong electromagnetism.

3) power pressure zone should not be over the setting press ±10%



2, Configuration

2.1 machinery part

Name Manufacture Note

Chain Qingdao Main axis driving

Qiangzhu speed reducerZhujiang Moving end box

Speed reducer Guomao Main axis speed reducing

Deep groove ball bearingHaerbin bearingMoving end box

Cone roller bearing Haerbin bearingMain axis, end axis loading



2.2 electric control part

Main component and supplier

Name Supplier Note

Transducer Mitsubishi

Programming controller PLCMitsubishi

Touching screenMitsubishi

Encoder Shanghai

Electromagnetism 3 phase synchronous motor ABB or famous brand

Foot switch Taiwan

Power button Schneider or DELIXI



2.3 technology documents

Including: coil winding operation manual, transducer operation manual, certificate of quality, packing list.



3, Sales Service:

A, we supply profession technology support and client information for client. If there is our machine user in client country, we can help client to our user to check our machine.

B, we can supply manufacture factory establish drawing for client factory building.

C, we can invite client to our factory for visiting and check our machine, talk face to face, we can use our professional knowledge and power to let you believe us.

D, if client need training, we can send our technology person to client factory to installing, adjusting and training of our machine. Give client full and exact training in using.

E, quality assurance time is 12 months, if our quality problem, we supply free service, if client problem, we just charge cost money.



4, Price and payment term:

4-1 price:

Contact with me forwardly. There is discount price for you!



4-2 payment term:

30% deposit and the balance paid before delivery by T/T.



5, Delivery time:

20 days after received the 30% deposit by T/T.
